| DATA SHEET |
|
|
|
|
|
| Rated Power |
1200 VA/1200 W |
2500 VA/2500 W |
3000 VA/3000 W |
5000 VA/5000 W |
| INPUT
|
| Voltage |
230 VAC |
| Selectable Voltage Range |
170 - 280 VAC (For Personal Computers); 90 - 280 VAC (For Home Appliances)
|
| Frequency Range |
50 Hz / 60 Hz (Auto sensing) |
| OUTPUT
|
| AC Voltage Regulation (Batt. Mode) |
230 VAC ± 5% |
| Surge Power |
2400 VA |
5000 VA |
6000 VA |
10000 VA |
| Efficiency (Peak) |
93% |
| Transfer Time |
10 ms (For Personal Computers); 20 ms (For Home Appliances) |
| Waveform |
Pure sine wave |
| No Load Consumption |
40 W |
| BATTERY
|
| Battery Voltage |
12 VDC |
24 VDC |
48 VDC |
| Floating Charge Voltage |
13.5 VDC |
27 VDC |
54 VDC |
| Overcharge Protection |
16 VDC |
32 VDC |
63 VDC |
| SOLAR CHARGER & AC CHARGER
|
| Solar Charger Type |
MPPT |
| Maximum PV Array Open Circuit Voltage |
350 VDC |
450 VDC |
500 VDC |
| Maximum PV Array Power |
2000 W |
3000 W |
5000 W |
| Maximum PV Input Current |
13 A |
18 A |
| MPP Range @ Operating Voltage |
30~300 VDC (30~60 VDC with battery connected) |
30~400 VDC (30~60 VDC with battery connected) |
60 ~ 400 VDC |
120 ~ 450 VDC |
| Maximum Solar Charge Current |
100 A |
| Maximum AC Charge Current |
80 A |
60 A |
100 A |
| Maximum Charge Current |
100 A |
| PHYSICAL
|
| Dimension, D x W x H (mm) |
90 x 288 x 357 mm |
110 x 288 x 390 mm |
90 x 288 x 357 mm |
120 x 300 x 440 mm |
| Net Weight (kg) |
6.5 kg |
7.0 kg |
7.2 kg |
7.0 kg |
10.0 kg |
| Communication Interface |
RS232 / RS485 |
RS232 / RS485, optional Wi-Fi |
RS232 / RS485 |
RS232 / RS485, optional Wi-Fi |
| OPERATING ENVIRONMENT
|
| Humidity |
5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature |
-10°C to 50°C |
| Storage Temperature |
-15°C to 60°C |
|
